SiC Schottky diode overview
Compared to standard silicon bipolar diodes, SiC Schottky Diodes havenegligible reverse recovery, which reduces switching losses and enablesdramatic increases in system efficiency. with near zero switching loss, heightened efficiency, and reduced heat dissipation. Topdiode’s SiC Schottky diode are perfect for power supplies, induction heating, welding, and high-temperature settings.
Topdiode’s SiC Schottky diode is an industrial-grade device with 650 V repetitive peak reverse voltage (VRRM) and 10 A continuous forward current (IF), designed to combine ultra-high performance and high efficiency with low energy loss in power conversion applications. Providing the added benefit of a high-voltage compliant real 2-pin (R2P) package with higher creepage distance, it is available in a choice of surface mount (DPAK R2P and D2PAK R2P) or through-hole (TO-220-2, TO-247-2) devices. Engineering samples are available on request.
Regarding SiC Schottky diode, The superior reverse recovery of these diodes translates to high efficiency in real-world use, one notable example in power supplies for industrial applications
Topdiode’s SiC Schottky diodes initially target industrial and consumer applications including:
* Switch Mode Power Supply (SMPS)
* AC-DC and DC-DC converters
* Battery charging infrastructure
* Uninterruptible Power Supply (UPS)
* Photovoltaic inverters
* Boost diodes in PFC or DC/DC stages
* Switch-mode power supplies
* Uninterruptible power supplies
* Solar inverters
* Industrial motor drives
* EV charging stations
About Topdiode
Topdiode is a leading expert in the high-volume production of essential semiconductors, components that are required by every electronic design in the world. The company’s extensive portfolio includes diodes, bipolar transistors, ESD protection devices, MOSFETs, Driver IC and Audio IC. These products are recognized as benchmarks in efficiency – in process, size, power and performance — with industry-leading small packages that save valuable energy and space.
Topdiode has expanded its portfolio of SiC diodes to include options that operate at 650 V and 1200 V with current ratings ranging from 6A to 50 A. Samples and production quantities of these new SiC diodes are now available.
Why choose Topdiode SiC Schottky Diodes?
Lower System Cost
Device redundancy is not needed
Ability to focus on the next generation of products instead of redesigning
No supply interruption of production
Faster to Market
Minimization of system development time
Earlier and more revenue
Ability to accelerate your innovation process
Lower Risk
Higher reliability and system lifetime
Lower component count
Multiple epi sources and fabs
650V SiC diodes product
Topdiode offers a complete range of 650V products that can serve as replacements for other brands, such as ST, Cree, GeneSiC, Infineon, MCC, on semi
| SiC Parameter | Brand / Part number | Brand / Part number |
| 650V, 8A SiC Schottky diode | Topdiode TPDA8S65C1P | GeneSiC GE08MPS06A |
| 650V, 10A SiC Schottky diode | Topdiode TPDE10S65C1P | Infineon IDD10SG60CXTMA2 |
| 650V, 15A SiC Schottky diode | Topdiode TPDA15S65C1P | Infineon IDH16G65C6 |
| 650V, 20A SiC Schottky diode | Topdiode TPDD20A65C1P | ST STPSC20H065CW |
| 650V, 40A SiC Schottky diode | Topdiode TPDH40S65C1P | MCC SICP4060Y-BP |
| 650V, 50A SiC Schottky diode | Topdiode TPDH50S65C1P | MCC SICP5060Y-BP |
For further question or inquiries, please kindly contact Loie: sales4@topdiode.com, or visit our website: www.topdiodes.com thanks
